Lafferty Metering Tip Calculator

Metering Tip Calculator

Lafferty Push-Lever Mixing Stations — find the correct color pin for your dilution

Your dispenser

Sets every lever below; you can override each lever’s pressure individually. Range 25–125 PSI.

Set each lever

Read each lever left to right — injector, gauge pressure, then your target as a dilution ratio (1:X) or ounces per gallon. Enter either one and the other fills in automatically. KennelSol = 1:64 = 2 oz/gal.

How to read this: insert the recommended color metering tip into that lever's tip holder. For a stronger mix, size to the next larger tip; for a leaner mix, size to the next smaller tip. Do not over-tighten.

Ratios are approximate and based on water-thin chemicals (~1 CPS viscosity); thicker chemicals draw less and may need a larger tip. Confirm final strength by application results. Where “No metering tip” is shown, leave the holder empty for the strongest mix. For ratios leaner than a single tip allows, use double dilution or contact us.

Based on Lafferty Equipment Manufacturing published metering-tip data (models 981100 / 981200 / 981400). © 2026 Alpha Tech Pet, Inc.  ·  alphatechpet.com
